D class Fire Extinguisher SP and C Type

Application Area

Metal processing industries

Manufacturing and machining plants

Chemical and pharmaceutical industries

Laboratories and research centers

Aerospace and defense workshops

Foundries and casting units

Welding and fabrication workshops

Warehouses storing combustible metal materials

Overview

D Class Fire Extinguisher (SP & C Type)

Metal fires present unique challenges and risks because burning metals can react violently with water, foam, or other conventional extinguishing agents. In many cases, these substances can intensify the fire or cause explosions. The D Class Fire Extinguisher (SP & C Type) is specifically designed to safely suppress fires involving combustible metals.

This extinguisher contains a special dry powder extinguishing agent developed for high-temperature metal fires. When discharged, the powder spreads over the burning metal surface and forms a thick heat-resistant layer. This layer acts as a barrier that isolates the burning metal from oxygen, preventing the fire from continuing its chemical reaction.

ITEM CODE	FL013	FL014	FL015	FL016	FL017	FL018
Type	Stored Pressure	Stored Pressure	Stored Pressure	Stored Pressure	Trolley Mounted	Trolley Mounted
Capacity	4 kg	6 kg	9 kg	25 kg	50 kg	75 kg
Height (Approx.)	490 mm	550 mm	645 mm	980 mm	1020 mm	1030 mm
Diameter (Approx.)	140±10 mm	150±10 mm	180±10 mm	300±10 mm	400±10 mm	400±10 mm
Average Discharge Time	18 sec	25 sec	30 sec	45 sec	75 sec	90 sec
Average % Discharge	85%	85%	85%	85%	85%	85%
Operating Temperature	-30°C to +55°C	-30°C to +55°C	-30°C to +55°C	-30°C to +55°C	-30°C to +55°C	-30°C to +55°C
Max. Service Pressure (Pms)	17 bar	17 bar	17 bar	17 bar	17 bar	17 bar
Test Pressure	35 bar	35 bar	35 bar	35 bar	35 bar	35 bar
Expelling Agent	Nitrogen	Nitrogen	Nitrogen	Nitrogen	Nitrogen	Nitrogen
CO2 Gas Cartridges	N/A	N/A	N/A	500 gm / 1 kg	2 kg	2 kg
